Auto Switches D Series









Specification

Bore size(mm)

D-C73

D-Z73

D-A93

D-A73

Switch logic

No

Type

With contact magnetic piping type

Operating voltage

5~120DC/AC

Max. switch current

Max.100MA

Max. contact capacity

Max.10W

Internal consumption current

Non

Residual voltage drop

Max.2.5V

Leakage current

Non

Indicator

Red LED

Wire length

2M

Sensitive degree

60GS

Max. switching frequency

1000HZ

Operating temperature range

-10-70

Anti-strike

30G

Anti-shock

9G

Protective grade

IP67
