Rotary Joint AMC
|
Model |
||||||
|
AMC4-M5 AMC4-01 AMC4-02 AMC4-02 |
AMC6-M5 AMC6-01 AMC6-02 |
AMC8-02 AMC8-03 |
AMC10-02 AMC10-03 AMC10-04 |
AMC12-03 AMC12-04 |
AMC15-03 AMC15-04 AMC18-04 |
AMC22-03 AM C-04 |
|
Order code |
|||
|
AMC |
8 |
- |
20 |
|
Series code |
Tube size 4 6 8 10 12 |
|
Port size 01:1/8" 02:1/4" 03:/3/8" 04:1/2" |
|
Specification |
||
|
Media |
Air |
|
|
Proof pressure |
1.32Mpa(1.35kgf/cm2) |
|
|
Pressure range |
Positive pressure |
0-0.9Mpa(0-9.2kgf/cm2) |
|
Negative pressure |
-99.99-0kpa(750-0mmHg) |
|
|
Ambient &fluid temperature |
0-60oc |
|
|
Recommended tubes |
Urethane tube ,nylon tube |
|
|
Material |
Brass |
|
